Touchscreens & Panel PCs

Extensive range of touchscreens and panel pcs

Commands range of products include:

All-In-One Media LCD Displays with built in media player and interactive touch screens ranging in size from 10" to 22"..

Panel PCs for commercial and industrial use with built-in computers ranging in size from 10" to 19".

Large Format Touch Screens with built-in computers ranging in size from 23" to 82".

All-In-One Small Format Touch Screens

The PAE series of touch screens are self-service terminal which integrates hardware and software to create an interactive environment such as product display for sale, and information display for multimedia.
The all-in-one network digital signage display are available in various sizes including 10"/ 15"/ 19"/ 22" available for selection.
The media files are on a local memory card with a built-in media player or the content can be sourced directly from a dweb server.
HTML and Flash are the primary supported file types.
The PAB1080PX Series are ideal for department stores, exhibitions, libraries, office buildings, airports, and other public places for advertising, presentations, training and other media applications.

Panel PC Touch Screens

The WLP series industrial panel PC includes full-line 10.4” to 19” LCD and touch panel integration. The WLP series support wide temperature fanless usage with stainless, aluminum or external heat sink rugged enclosure.
The rugged construction includes Lower Power and a true fanless thermal design.
The enclosures have a IP66 rated Water and Dust Proof front bezel.
The internals include a built-in HDD anti-vibration module.

Large Format Touch Screens

Project a professional image
Your large format LCD Touch Screen can be your first point of contact with your audience, and our large format touch screens are sure to leave a good first impression.
Our unique integrated touch screen solution allows for convenient set-up and enhances the user experience. Plus, the networking capabilities and built-in speakers will deliver the greater operational efficiency and impact you've come to expect from a quality product.
Integrated touch screen.
Unlike conventional large format screens, our screens have integrated a touch screen solution within range.
Simply plug it in and the LFD is ready to go with the infrared touch screen have a response time of 15 to 40ms,. These screens are some of the fastest on the market today and the enhanced sensitivity of the infrared touch screen makes it easy to operate.
The screens come with a 3mm protective LCD glass panel, so you can rest assured that your LCD will working for years to come.

Need more information?

For any questions about how a Command Digital Signage System would be suitable for your business or to arrange a time for an on-site or on-line demonstration, please contact us on 1300 780 204 or through our enquiry form.

Command products and solutions are also available through your local AV and IT professionals.

All-In-One (10"-22")
Panel PC (10"-19")
Large (23"-82")

All-In-One (10"-22") Features

PAE101V.I.P PRO: Built-in 10.1" LCD display (resolution up to 1024 x 600), resistive type touch and stereo speakers (1W x 2).

PAE15V.I.P PRO: Built-in 15" LCD display (resolution up to 1024 x 768), resistive type touch and stereo speakers (5W x 2).

PAE17V.I.P PRO: Built-in 17" LCD display (resolution up to 1024 x 768), resistive type touch and stereo speakers (5W x 2).

PAE19V.I.P PRO: Built-in 19" LCD display (resolution up to 1280 x 800), resistive type touch and stereo speakers (5W x 2).

PAE15V.I.P PRO: Built-in 19" LCD display (resolution up to 1024 x 768), capacitive type touch and stereo speakers (5W x 2).

PAE15V.I.P PRO: Built-in 22" LCD display (resolution up to 1680 x 1050), capacitive type touch and stereo speakers (5W x 2).

Supports Touch Screen function.
Supports CF memory card.
Supports 2 USB ports.
Provides RJ-45 port for connecting to an Ethernet network.
Supports VGA out for connecting to external monitor or projector.
Supports Audio output for connecting to external speakers.
Main function as below (under Linux OS)
Web based content (W3C WEB Standard) management solution allows you to edit and apply layout design easily.
Supports shockwave flash (SWF) format.
Supports Java Script/ Applets.
USB Auto-Copy Function: Automatically copy the contents from Pen Driver to CF card.
Virtual Keyboard: The virtual keyboard will automatically appear when selecting the entry field.
Supports External USB Printer.

Panel PCs

The range of panel pcs is extensive with many options. The following are a sub-set of available panel pcs.

Example Panel PC include:

10.4" LCD 800x600, Intel Atom N270 1.6GHz, Fanless, Resistive Touch

12" LCD 800x600, Intel Atom N270 1.6GHz, Fanless, Resistive Touch

15" LCD 1024x768, Intel Atom N270 1.6GHz, Fanless, Resistive Touch

17" LCD 1280x1024, Intel Atom N270 1.6GHz, Fanless, Resistive Touch

19" LCD 1280x1024, Intel Core Duo 2.16GHz, Fanless, Resistive/Cap./SAW/IR/PCT Touch

Large Format Touch Screens (23"-82")

High quality Professional Touch Screens..

SPECIFICATIONS

Size	23"	32"	40"	46"	65"	70"	82"
Resolution	1920 x 1080	1366 x 768	1920 x 1080	1920 x 1080	1920 x 1080	1920 x 1080	1920 x 1080
Dimensions (WxHxD mm)	557.5 x 339 x 79.2	787 x 482 x 116	973.2 x 584.4 x 128.1	1104.2 x 658.4 x 134.3	1554 x 924 x 138	1688 x 989 x 138	1915 x 1125 x 618
Display Area (WxH mm)	509 x 266	697 x 392	885 x 498	1018 x 572	1428 x 803	1549 x 871	1805 x 1015
Weight	8.38kg	20.8kg	27.2kg	31.3kg	70kg	122kg	140kg
Bezel Width	22.8/25.1mm	40mm	40mm	40mm	54mm	55mm	55mm
Inputs	VGA	VGA	VGA	VGA	VGA	VGA	VGA
External Control	RS232	RS232, RJ45	RS232, RJ45	RS232, RJ45	RS232, RJ45	RS232	RS232
Built-in Computer	Internal	Internal	Internal	Internal	Internal	Internal	Internal
Power Consumption	Max 120W/h	Max 220W/h	Max 220W/h	Max 320W/h	Max 470W/h	Max 879W/h	Max 1000W/h

Specifications are subject to change.

Advanced Commercial Grade LCD Displays

Ideal for 24 hour operation in Digital Signage or other display requirements.
